Cellular Confinement System Reinforced Soil Slope Stabilizer Gravel Grid HDPE Geocell 445mm

Name: Cellular Confinement System Reinforced Soil Slope Stabilizer Gravel Grid HDPE Geocell 445mm
Brand: Geomax
Price: 1 USD

China Cellular Confinement System Reinforced Soil Slope Stabilizer Gravel Grid HDPE Geocell 445mm wholesale

Brand Name : Geomax

Model Number : 1.5-100-445

Certification : CE

Place of Origin : ANHUI CHINA

MOQ : 1000 ㎡

Price : Negotiation

Payment Terms : T/T, L/C

Supply Ability : 2000㎡ per day

Delivery Time : 10-20 days

Packaging Details : Folded strips are wrapped by film and layed on pallets or as requested

Raw Material : HDPE Plastic

GeoMax Standard : ASTM

Cell Height : 50mm-300mm

Geomax Model : GM445

Color : Black, green, brown, Black Yellow White Green, Green or as per request

Welding Space : 445mm

Cell Thickness : 1.5mm

Geocell Surface : Textured&Perforated

Contact Now

Cellular Confinement System Reinforced Soil Slope Stabilizer Gravel Grid HDPE Geocell 445mm

Product Introduction

Geocell is a mesh structure formed by high-strength HDPE or PP copolymer broadband, which is welded or riveted by strong force It can stretch and fold freely during transportation, and when in use, it can be opened and filled with soil, rock or concrete materials, forming a structure with strong lateral restraint and high stiffness It can be used as a cushion layer to increase the bearing capacity of weak foundations, and can also be laid on slopes to form slope protection structures. It can also be used to construct retaining structures, reinforce foundations, and protect railway slopes The application of geosynthetic materials in highways is becoming increasingly widespread. Practice has proven that geosynthetic cells are a new type of highway construction material with more advantages, strong practicality, suitable price, and good application effects compared to other geosynthetic materials

Specifications

Index Properties	Test Method			Units				Values
Material	-			-				100% Virgin HDPE
Carbon Black content	ASTM D 1603			%				≥1.5
Density	ASTM D 1603			g/cm3				0.935-0.965
Sheet Thickness ± 3%	ASTM D 5199			mm				1.5
Seam Peel Strength	USACE GL-86-19			KN/m				≥14.2
Tensile strength at Yield	ASTM D 1603			KN/m				≥22
Environmental stress crack resistance	ASTM D 1603			hrs				≥5000
OIT oxidation induction time	ASTM D 1603			min				≥150

Type	GM330	GM356	GM400		GM432	GM445	GM500		GM660	GM712
Welding Distance(mm) ± 3%	330	356	400		432	445	500		660	712
Cell Depth(mm) ± 3%	50,75,100,150,200,250
Dimensions
Expanded Cell Size (width×length) (mm) ± 3%	250 x 210	260 x 225	290 x 260		320 x 275	315 x 300	360 x 300		470 x 450	510 x 475
Expanded Cell numbers(width×length)	10 x 34	9 x 34	8 x 34		8 x 34	8 x 34	7 x 34		5 x 34	5 x 34
Expanded Section size (width×length) (m) ± 3%	2.50 x 7.14	2.34 x 7.65	2.32 x 8.84		2.56 x 9.35	2.52 x 10.2	2.52 x 11.22		2.35 x 15.3	2.55 x 16.15
Expanded Section Area (m2) ± 5%	17.85	17.9	20.5		23.94	25.7	28.74		35.95	41.18

APPLICATION

Cellular Confinement System Reinforced Soil Slope Stabilizer Gravel Grid HDPE Geocell 445mm

SOIL REINFORCEMETN

Geomax®(Hdpe Geocell) is the solution to soil stabilization or soil reinforcement. It can increase the bearing capacity of the pavement and avoid cracking of the pavement.

SLOPE PROTECTION

Geomax®(Hdpe Geocell) is the obvious choice for slope protection or erosion control. It has both good drainage effect and slope protection.

CHANNEL PROTECTION

Geomax®(Hdpe Geocell) delivers stability and protection of channels
exposed to erosive conditions ranging from low to high flows, either intermittent or continuous.

RETAINING WALLS

Geomax®(Hdpe Geocell) offers highly permeable and acts as a great number of planting pots, allowing rainwater to infiltrate, minimizing runoff.
